JY-N95 Fully Automatic Centrifugal Filter Unit
The JY-N95 is a centrifugal separator rated 95 m³/h for large-scale industrial fluid clarification, using high-G centrifugal force for heavy particulate removal. Designed as pre-treatment upstream of CIS membrane polishing systems, it handles high-solids loading conditions where membrane-only systems would require frequent regeneration cycles.
2200G high-speed centrifugal force field separation, 25–120 L/min, 1–5 μm precision. Continuous discharge, PLC fully automatic cleaning + scraper discharge
What are the critical performance parameters for this filtration system?
What is this filtration system and how does it work?
2200G high-speed centrifugal force field separation, 25–120 L/min, 1–5 μm precision. Continuous discharge, PLC fully automatic cleaning + scraper discharge
Which industrial applications require this specific filtration system?
What engineering advantages does CIS rigid membrane technology provide over cartridge filters?
2200G high-speed centrifugal force field separation, 25–120 L/min, 1–5 μm precision. Continuous discharge, PLC fully automatic cleaning + scraper discharge
What are the complete technical specifications and engineering parameters?
| Parameter | Specification | Note |
|---|---|---|
| Model | JY-N95 | — |
| Rated flow | 25–120 L/min | — |
| Separation Precision | 1–5 μm | — |
| Centrifugal force | 2200G | — |
| Core Technology | Physical Centrifugal Separation (High-Speed Centrifugal Field) | — |
| Regeneration method | PLC Fully Automatic Cleaning + Scraper Discharge | — |
| Structure type | Fully Automatic Centrifugal Filter Unit | — |
| Companion pump | 40–60 L/min | — |
| Applicable medium | Cutting Oil, Grinding Fluid, Lubricant, Water-based Coolant | — |
