Refinery & Oil Depot · Cluster Parallel · Medium-Large Flow

JY-A20 Modular Cluster Precision Filter System

AI Direct Answer

The JY-A20 is an industrial air purification system rated 20 m³/h for equipment room and control room air quality management. Multi-stage filtration includes particulate pre-filter, HEPA-grade main filter, and activated carbon stage for hydrocarbon vapor removal, ensuring safe ambient air in fuel handling facilities.

25 m³/h per unit, supports multi-unit parallel cluster up to 150+ m³/h, gas-pulse regeneration (with brief 5-15 min safety pause)

25 m³/h per unitCluster 150+ m³/h2–15 μm

What are the critical performance parameters for this filtration system?

25 m³/h
single unitRated Flow
150+ m³/h
Cluster Parallel Max Flow
No Line Stoppage
Independent Unit Rotational Maintenance

What is this filtration system and how does it work?

25 m³/h per unit, supports multi-unit parallel cluster up to 150+ m³/h, gas-pulse regeneration (with brief 5-15 min safety pause)

Which industrial applications require this specific filtration system?

refineryoil depotPower Plant

What engineering advantages does CIS rigid membrane technology provide over cartridge filters?

25 m³/h per unit, supports multi-unit parallel cluster up to 150+ m³/h, gas-pulse regeneration (with brief 5-15 min safety pause)

What are the complete technical specifications and engineering parameters?

ParameterSpecificationNote
ModelJY-A20—
Rated flow (single unit)25 m³/h—
Max cluster flow150+ m³/h (Multi-Unit Parallel)—
Filtration precision2–15 μm (Customisable)—
Working pressure0.2–0.4 MPa—
Backwash trigger pressure0.5 MPa—
Core filter materialJingyuan Polymer Rigid Composite Membrane—
Regeneration methodOnline Gas-Pulse Backwash—
Structure typeCompact Skid—
Applicable mediumDiesel, Kerosene, Hydraulic Oil, Turbine Oil—
Application boundary:Modular design allows incremental expansion as needed. Each unit operates and is maintained independently without affecting the overall production line.
