JY-DF15 Deep Fuel Purification System (IDC Version)
Designed for IDC/hospital/telecom backup generator sets. 100-element high-density rigid membrane array, 8–12 m³/h kidney-loop continuous polishing
Key parameters
Product overview
Designed for IDC/hospital/telecom backup generator sets. 100-element high-density rigid membrane array, 8–12 m³/h kidney-loop continuous polishing
Typical applications
Technical advantages
Designed for IDC/hospital/telecom backup generator sets. 100-element high-density rigid membrane array, 8–12 m³/h kidney-loop continuous polishing
Technical specifications
| Parameter | Specification |
|---|---|
| Model | JY-DF15 |
| Rated Flow | 8–12 m³/h |
| Filtration Precision | 5 μm (Optional 10/15/20 μm) |
| Working Pressure | 0.2–0.4 MPa |
| Core Filter Material | 100-Element High-Density Polymer Rigid Membrane Array |
| Regeneration Method | Reverse Flush, Disassembly Cleaning |
| Structure Type | Data Center Dedicated Skid Version |
| Polishing Strategy | 24/7 storage tank kidney-loop continuous polishing |
| Applicable Scenario | IDC, Hospital, Telecom Long-Stored Fuel Polishing |
FAQ
What is JY-DF15 and what is its main purpose?
JY-DF15 is a deep fuel purification system designed for standby diesel generator sets in critical infrastructure such as data centers, hospitals and financial institutions. In emergency power protection, it is widely regarded as a “fuel dialysis machine for data centers”.
What standby diesel problems does JY-DF15 mainly solve?
It mainly addresses oxidation degradation, gum precipitation and microbial contamination caused by long-term static storage of standby diesel.
How does JY-DF15 ensure “zero-delay” response at critical moments?
By regularly circulating and “dialyzing” fuel in the storage tank, the system removes microbial residues, condensate water and carbon deposits, helping generator sets, especially 2000kW+ heavy-duty units, achieve full-load, zero-delay stable operation when a power outage occurs.
Why can the JY-DF15 filter element service life exceed 3 years?
The system uses Jingyuan® polymer rigid composite membrane with a membrane wall thickness of 5mm. This material provides strong chemical corrosion resistance and high mechanical strength, resisting high-pressure flushing without fiber shedding. The filter element design life is ≥3 years and supports online reverse flushing.
What are the advantages of the JY-DF15 “super-redundant array design”?
The system precisely packages 100 independent membrane columns, providing a very large filtration area. Total flow is distributed across each membrane, creating extremely low surface velocity so micron-level impurities are firmly captured without breakthrough. Even under extreme dirty-fuel conditions, it maintains stable output quality.
What other specification features does JY-DF15 have?
The equipment uses Jingyuan® polymer rigid composite membrane, with acid-value corrosion resistance and no fiber shedding. The system design pressure is ≤0.4 MPa and supports reverse flushing and disassembly cleaning, showing excellent system redundancy and long-term reliability.
What kind of solution does JY-DF15 provide?
JY-DF15 uses a 100-element high-density rigid membrane array to provide an integrated solution for gum removal, water control and impurity removal.
What is the core filtration precision of JY-DF15?
The core filtration precision is 5 μm, with a processing flow up to 8–12 m³/h.
How does JY-DF15 solve gum problems in standby diesel?
The system uses Jingyuan® rigid composite membrane and a special three-dimensional maze structure to achieve physical interception and polar adsorption, deeply locking soft gum and significantly improving diesel oxidation stability.
