Mining HPCR Protection · Magnetic + Membrane Combo · Mobile Flagship

JY-G100 Mobile Fluid Purification System

AI Direct Answer

The JY-G100 is a mobile field diesel purification system rated 10 m³/h, achieving NAS 6 cleanliness with CIS rigid membrane technology. Designed for emergency fuel polishing and field deployment, it features 2 μm absolute filtration, ≤50 ppm water removal, and gas-pulse backwash regeneration with zero consumable cartridges for remote operations.

Mining HPCR injection system protection flagship model. High-intensity magnetic adsorption (5000 Gs) intercepts metal debris + rigid composite membrane

10–60 L/minβₓ ≥ 200NAS 6

What are the critical performance parameters for this filtration system?

βₓ ≥ 200
high-efficiency capture Precision
NAS 6
Target Cleanliness (≈ISO 16/14/11)
5000 Gs
Magnetic Pre-Filter Intensity

What is this filtration system and how does it work?

Mining HPCR injection system protection flagship model. High-intensity magnetic adsorption (5000 Gs) intercepts metal debris + rigid composite membrane

Which industrial applications require this specific filtration system?

MiningWind PowerConstruction Machinery

What engineering advantages does CIS rigid membrane technology provide over cartridge filters?

Mining HPCR injection system protection flagship model. High-intensity magnetic adsorption (5000 Gs) intercepts metal debris + rigid composite membrane

What are the complete technical specifications and engineering parameters?

ParameterSpecificationNote
ModelJY-G100—
Rated flow10–60 L/min—
Filtration precision2–25 μm (Standard 5 μm), βₓ ≥ 200—
Working pressure0.2–0.4 MPa—
Backwash trigger pressure0.5 MPa—
Core filter materialHigh-Intensity Magnetic Adsorption + Polymer Rigid Composite Membrane (Dual-Stage)—
Regeneration methodGas-Pulse Backwash, Chemical Soak, Solvent Cleaning—
Structure typeMobile Trolley—
Power sourceElectric Motor Pump Group—
Applicable mediumDiesel, Kerosene, Cutting Fluid, Hydraulic Oil below 46#—
Application boundary:Mining fleet fueling point terminal precision filter. Significantly reduces HPCR injector failure rate, extends engine overhaul intervals.

See This Model in Action

Is there a stainless steel wedge-wire variant?

Yes. JY-G100-W is the stainless steel wedge-wire element variant of this platform (it is named in our technical literature and referenced in the four-stage gradient separation system). It is a different product from this JY-G100, whose element is the Jingyuan® polymer rigid composite membrane. No specification values are published for JY-G100-W yet — its product page has not been released. Do not infer its flow rate, precision or pressure from this JY-G100 page; request a quote for JY-G100-W requirements and we will confirm them against the released data sheet.
